Smart LiFePO4 Battery
Chargers
Chargers
GWBTEK smart chargers go beyond simple charging, integrating advanced technology to deliver optimized power, enhanced safety, and unparalleled convenience for a wide range of applications.
-
12V -
24V -
36V -
48V
Main Features
-
the intelligent brain of the charger, which constantly analyzes and adjusts the charging parameters in real-time for maximum efficiency and battery care. -
Intelligently monitors the battery status and automatically switches from fast charge to trickle charge upon reaching full capacity, preventing overcharging. -
Built-in safeguards including Over-Charge Protection, Short-Circuit Protection, Over-Voltage Protection, and Temperature Control ensure complete safety for both the charger and your valuable batteries -
To recover and activate batteries that have entered an "over-discharged" or "sleep" mode due to self-discharge or prolonged storage.
Parameters
12V-24V
- 14.6V10AH
| Model | GWB30V146A100 |
| Battery Type | Lithium-Ion Battery |
| Charging Mode | CC/CV |
| Range of Input Voltage | 100~240VAC |
| Range of Input Frequency | 50-60Hz |
| Efficiency | 85% min.@100VAC / 88% min.@240VAC (Full load) |
| Input AC Current | 5A max. @100VAC input & (Full load) |
| Rated Voltage | 14.6V |
| Rated Current | 10A±3% |
| Rated Power | 146W |
| Standby Power | ≤5W |
| Operating Temperature | -25°C~+45°C |
| Weight | 0.94kg |
| Dimensions(L*W*H) | 172.5mm*90.5mm*51mm |
